23
ST SERIES
ENGINE DISASSEMBLING
• Remove the needle cage
9
, and the clutch
basket
q
.
• Remove the washer
w
.
• Remove the snap ring
e
and the crankshaft gear
r
.
• Remove the spring washer
t
.
• Remove the snap ring
y
from the crankshaft

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SHERCO 125 and is the answer not in the manual?

SHERCO 125 Specifications

General IconGeneral
StarterKick starter
Bore x Stroke54 mm x 54.5 mm
Cooling SystemLiquid
Transmission6-speed
Front BrakeDisc
Rear BrakeDisc
Displacement124.8 cc
