Shimadzu GCMS-QP2010 - Page 124

ZEBV-5020C
(*) Use a step-up transformer from a 100V or 200V amplifier. The maximum current
with a 100VAC power supply is approximately 26A (with no options). Ensure the
wiring has sufficient capacity. Use of the following step-up transformers is
recommended.
Cat. No. Description Capacity
Cable
length
Terminal
type
225-10690-91
Step-up transformer for
200VAC
3kVA 3.0m Fig. 1
Fig. 1
Fig. 2
Black
White
Green
