Shimadzu GCMS-QP2010 User Manual

List of Service Parts and Consumables (for replacement by service technicians)
P/N Description Comment
Replacement
frequency
(guideline)
Class
221-46260-91
KEY OPERATION UNIT (PCB) Service part
078-12130-01
KEY OPERATION UNIT (LCD) Service part
221-46470
KEY OPERATION UNIT KEY RUBBER 1 (UPPER) Service part
221-46471
KEY OPERATION UNIT KEY RUBBER 2 (LOWER) Service part
221-43695-91
THERMAL SENSOR (for column)
Service part
GC
221-43696-91
THERMOCOUPLE (for column) Service part
225-10547
INSULATOR, I/F Service part
018-23651
TAPE #973 Service part
036-11251
O-RING 4D P50 Service part
225-10549-91
HEATER BLOCK ASSY 100 to 115V, incorporates heater and
PT sensor
Service part
I/F
225-10549-92
HEATER BLOCK ASSY
220 to 240V, incorporates heater and
PT sensor
Service part
200-44394
CERAMIC INSULATOR, A24-251-1 As required Consumable
225-10439-91
HEATER BLOCK ASSY Service part
225-10436-91
PT ASSY, IS Service part
018-17301
ALUMINUM FOIL As required Consumable
225-10200-91
IS ASSY
LENS, MAGNET, HEATER Service part
225-10554-91
CPU, I/F A ASSY Service part
034-01602-31
SPRING, SUS UR8-10 Service part
225-10434-91
CABLE ASSY, F1(S) Service part
225-10434-92
CABLE ASSY, F2(S) Service part
225-10434-93
CABLE ASSY, F1(L)
Service part
225-10434-94
CABLE ASSY, F2(L) Service part
IS
225-10434-95
CABLE ASSY, L1 Service part
225-10463-91
EM(H) ASSY Entire detector Service part
225-09340-11
EM, AF620 Electron multiplier only 1 part/3 years Consumable
225-10466-91
SIG CABLE ASSY, DET Service part
225-10466-92
LENS CABLE ASSY, DET Service part
DET
225-10466-93
HV CABLE ASSY, DET Service part
