- 119 -
3. Remove the front cover.
Loosen the screws at the both
sides of cover.
Remove the front door.
Remove the cover.
Remove
the screw.
Loosen the
screw
Loosen the
screw
Remove
the screw.
Remove
the screw.
Remove
the screw.
