Chapter 12 Operating Instructions
C 4000 Standard/Advanced
90 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8 009 861/OE59/19-11-04
Ordering information
Part Part number
C 4000-extension connection
Hirschmann cable socket M26)×)11 + FE, crimp contacts, straight 6 021 191
Connecting cable for the connection of guest 1 or guest 2
Plug straight/socket straight, 0.25 m 2 022 278
Plug straight/socket angled, 0.25 m 2 022 284
Plug straight/socket straight, 0.5 m 2 021 838
Plug straight/socket angled, 0.5 m 2 022 285
Plug straight/socket straight, 1 m 2 022 279
Plug straight/socket angled, 1 m 2 022 286
Plug straight/socket straight, 1.5 m 2 022 280
Plug straight/socket angled, 1.5 m 2 022 287
Plug straight/socket straight, 2 m 2 022 281
Plug straight/socket angled, 2 m 2 022 288
Plug straight/socket straight, 2.5 m 2 022 282
Plug straight/socket angled, 2.5 m 2 022 289
Plug straight/socket straight, 3 m 2 022 283
Plug straight/socket angled, 3 m 2 022 290
Other accessories
Mounting kit 2: swivel mount, 4 pcs. for any protective field height 2 019 659
Mounting kit 6: swivel function (side bracket), 4 pcs. for any protective
field height. For higher vibration and shock exposure
2 019 506
Switching amplifier UE 402: Expands the C 4000 with the functions
PSDI mode, bypass, operating mode changeover
1 023 577
Connection cable M8)×)4/D-Sub 9-pin (DIN 41)642); for connecting the
configuration interface and the serial interface of the PC
2 m 6 021 195
8 m 2 027 649
Accessories included in a standard delivery
Sliding nuts for side bracket, 4 pcs. 2 017 550
CDS (Configuration & Diagnostic Software) on CD-ROM including
online documentation and operating instructions in all available
languages
2 026 875
$ The minimum bending radius of the cables is 150 mm.
$ The cable sheath is made of PVC (UL listed).
