SICK C 4000 User Manual

Operating Instructions Chapter 4
C 4000 Standard/Advanced
8 009 861/OE59/19-11-04 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
31
Configurable functions
4.8.3 Effective resolution for blanking
The effective resolution of an optical system depends on both its optical components and
on its configuration. The effective resolution cannot be higher than the highest possible
physical resolution of the system. However, it can be reduced by the configuration, e.g. by
blanking beams.
In conjunction with size tolerance, the effective resolution is reduced at the edges of the
blanked areas. For blanking with size tolerance, the effective resolution depends on the
physical resolution and the size tolerance chosen.
Check the safety distance!
When using floating blanking with increased size tolerance, the required safety distance
will depend on the effective resolution (see Tab. 10).
 If required, recalculate the safety distance and readjust it on the machine.
Example: – physical resolution 14 mm
– size tolerance –2 beams
– effective resolution 22 mm
Calculate the safety distance with a resolution of 22 mm (see page 37).
 Mark the effective resolution on the information label “Operation with blanking
combined with size tolerance …” on the related sender and receiver.
%
Warning: During operation with “Blanking” combined with “Size tolerance”, the safety
distance that corresponds to the modified resolution is to be observed.
Physical resolution
Resolution modified to:
(please mark)
14 mm 20 mm 30 mm 40 mm
Size tolerance Effective resolution
1 beam 14 mm 9 20 mm 40 mm 60 mm
2 beams 22 mm 30 mm Not possible Not possible
4 034 160
Physical
resolution
Size tolerance Effective resolution at the
edges of the blanked area
Permissible types of
blanking
14 mm Without 14 mm Fixed
–1 beam 14 mm Fixed and floating
–2 beams 22 mm Floating
20 mm Without 20 mm Fixed
–1 beam 20 mm Fixed and floating
–2 beams 30 mm Floating
30 mm Without 30 mm Fixed
–1 beam 40 mm (no PSDI mode) Fixed and floating
–2 beams Not permitted Not permitted
40 mm Without 40 mm Fixed
–1 beam 60 mm Fixed and floating
–2 beams Not permitted Not permitted
%
WARNING
Fig. 16: Marking the effective
resolution on the device label
Tab. 10: Effective resolution
for blanking with size
tolerance
