SICK C 4000 User Manual

Chapter 12 Operating Instructions
C 4000 Standard/Advanced
86 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8 009 861/OE59/19-11-04
Ordering information
12.3 System with extension connection
For use as single system, as host or as first or second guest of a cascaded system.
12.3.1 C 4000 Standard with extension connection
Part numbers for resolutionProtective field
height [mm]
14 mm 20 mm 30 mm 40 mm
300
# 1 018 690
(C40S-0301DA010)
" 1 018 691
(C40E-0301DA010)
# 1 018 710
(C40S-0302DA010)
" 1 018 711
(C40E-0302DA010)
# 1 018 733
(C40S-0303DA010)
" 1 018 734
(C40E-0303DA010)
# 1 018 755
(C40S-0304DA010)
" 1 018 756
(C40E-0304DA010)
450
# 1 018 349
(C40S-0401DA010)
" 1 018 350
(C40E-0401DA010)
# 1 018 712
(C40S-0402DA010)
" 1 018 713
(C40E-0402DA010)
# 1 018 735
(C40S-0403DA010)
" 1 018 736
(C40E-0403DA010)
# 1 018 757
(C40S-0404DA010)
" 1 018 758
(C40E-0404DA010)
600
# 1 018 692
(C40S-0601DA010)
" 1 018 693
(C40E-0601DA010)
# 1 018 714
(C40S-0602DA010)
" 1 018 715
(C40E-0602DA010)
# 1 018 737
(C40S-0603DA010)
" 1 018 738
(C40E-0603DA010)
# 1 018 759
(C40S-0604DA010)
" 1 018 760
(C40E-0604DA010)
750
# 1 018 694
(C40S-0701DA010)
" 1 018 695
(C40E-0701DA010)
# 1 018 716
(C40S-0702DA010)
" 1 018 717
(C40E-0702DA010)
# 1 018 739
(C40S-0703DA010)
" 1 018 740
(C40E-0703DA010)
# 1 018 762
(C40S-0704DA010)
" 1 018 763
(C40E-0704DA010)
900
# 1 018 696
(C40S-0801DA010)
" 1 018 697
(C40E-0801DA010)
# 1 018 718
(C40S-0802DA010)
" 1 018 719
(C40E-0802DA010)
# 1 018 741
(C40S-0803DA010)
" 1 018 742
(C40E-0803DA010)
# 1 018 765
(C40S-0804DA010)
" 1 018 766
(C40E-0804DA010)
1050
# 1 018 698
(C40S-1001DA010)
" 1 018 699
(C40E-1001DA010)
# 1 018 720
(C40S-1002DA010)
" 1 018 721
(C40E-1002DA010)
# 1 018 743
(C40S-1003DA010)
" 1 018 744
(C40E-1003DA010)
# 1 018 767
(C40S-1004DA010)
" 1 018 768
(C40E-1004DA010)
1200
# 1 018 700
(C40S-1201DA010)
" 1 018 701
(C40E-1201DA010)
# 1 018 722
(C40S-1202DA010)
" 1 018 723
(C40E-1202DA010)
# 1 018 745
(C40S-1203DA010)
" 1 018 746
(C40E-1203DA010)
# 1 018 769
(C40S-1204DA010)
" 1 018 770
(C40E-1204DA010)
1350
# 1 018 702
(C40S-1301DA010)
" 1 018 703
(C40E-1301DA010)
# 1 018 724
(C40S-1302DA010)
" 1 018 725
(C40E-1302DA010)
# 1 018 747
(C40S-1303DA010)
" 1 018 748
(C40E-1303DA010)
# 1 018 771
(C40S-1304DA010)
" 1 018 772
(C40E-1304DA010)
1500
# 1 018 704
(C40S-1501DA010)
" 1 018 705
(C40E-1501DA010)
# 1 018 726
(C40S-1502DA010)
" 1 018 727
(C40E-1502DA010)
# 1 018 749
(C40S-1503DA010)
" 1 018 750
(C40E-1503DA010)
# 1 018 773
(C40S-1504DA010)
" 1 018 774
(C40E-1504DA010)
1650
# 1 018 706
(C40S-1601DA010)
" 1 018 707
(C40E-1601DA010)
# 1 018 728
(C40S-1602DA010)
" 1 018 729
(C40E-1602DA010)
# 1 018 751
(C40S-1603DA010)
" 1 018 752
(C40E-1603DA010)
# 1 018 775
(C40S-1604DA010)
" 1 018 776
(C40E-1604DA010)
1800
# 1 018 708
(C40S-1801DA010)
" 1 018 709
(C40E-1801DA010)
# 1 018 730
(C40S-1802DA010)
" 1 018 731
(C40E-1802DA010)
# 1 018 753
(C40S-1803DA010)
" 1 018 754
(C40E-1803DA010)
# 1 018 777
(C40S-1804DA010)
" 1 018 778
(C40E-1804DA010)
Tab. 42: Part numbers
C 4000 Standard with
extension connection
