Chapter 11 Operating Instructions
C 4000 Standard/Advanced
74 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8 009 861/OE59/19-11-04
Technical specifications
11.4.2 C 4000 Standard with angled system connection and without extension
connection
Protective field height
S [mm]
Dimension
L1 [mm]
Dimension
L2 [mm]
Dimension
A [mm]
300 381 397 224
Other systems on request.
Fig. 39: Dimensional drawing
C 4000 Standard, sender
with angled system
connection and without
extension connection.
Receiver, mirror image
Tab. 31: Dimensions
dependent on the protective
field height, C 4000 Standard
with angled system
connection and without
extension connection
48
22.4
74 A
Sliding nut groove for
side mounting
14
6
10.5
2.2
1
3.5
10
DIN 43
)
651 plug (M26
)
×
)
11 + FE)
40
20
L1
L2
56.3
S
6.3
92
Cable sockets M26
)
×
)
11 + FE
with crimp contacts
Ca. 95
(connector range)
67
Ca. 135
(connector range)
65
