SICK C 4000 User Manual

Chapter 4 Operating Instructions
C 4000 Standard/Advanced
36 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8 009 861/OE59/19-11-04
Configurable functions
4.11 Functions that cannot be combined
Function that can be
configured
Limitation
Teach-in key-operated
switch on the extension
connection
$ Emergency stop or bypass function can only be used in
conjunction with a SICK switching amplifier (teach-in on the
switching amplifier, emergency stop/bypass on the C 4000)
Emergency stop at
extension connection
$ Teach-in or bypass only possible in conjunction with SICK
switching amplifier. Either an emergency stop, a bypass or a
teach-in can be connected
Bypass at extension
connection
$ Emergency stop or teach-in function can only be used in
conjunction with a SICK switching amplifier (teach-in on the
switching amplifier, emergency stop/bypass on the C 4000)
Reduced resolution $ Not with floating blanking with partial object monitoring
$ Not with fixed blanking and increased size tolerance
Floating blanking with
partial object monitoring
$ Not with floating blanking with partial object monitoring
$ Cannot be used if a neighbouring area uses floating
blanking with complete object monitoring
$ Not with fixed blanking and increased size tolerance
$ Not with reduced resolution
Floating blanking with
complete object
monitoring
$ Cannot be used if a neighbouring area uses floating
blanking with partial object monitoring
$ Not with fixed blanking with increased size tolerance
Fixed blanking with
increased size tolerance
$ Not with floating blanking with partial object monitoring
$ Not with floating blanking with complete object monitoring
$ Not with reduced resolution
Tab. 13: Functions that
cannot be combined
