Operating Instructions Chapter 12
C 4000 Standard/Advanced
8 009 861/OE59/19-11-04 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
79
Ordering information
12 Ordering information
12.1 Delivery
C 4000 Standard
Delivery, sender
$ sender unit
$ 4 sliding nuts for side bracket
Delivery, receiver
$ receiver unit
$ 4 sliding nuts for side bracket
$ test rod with diameter corresponding to the physical resolution of the safety light curtain
$ label “Important Information”
$ operating instructions on CD-ROM
$ CDS (Configuration & Diagnostic Software) on CD-ROM
$ information label “Operator’s notes”
C 4000 Advanced
The C 4000 Advanced also includes:
$ additional test rods for testing the effective resolution:
– for 14 mm systems: diameters 22, 30 and 37 mm
– for 20 mm systems: diameters 30 and 40 mm
– for 30 mm systems: diameter 40 mm
$ information labels for the resolution of the device
If you want to use a C 4000 with function package B up to serial number 0231 9999, then
you will need a C 4000 Advanced. You will find the serial number on the type label on the
C 4000 in the Serial no field.
Pre-configured systems
The C 4000 Standard without extension connection is also available as an option with the
pre-configurations C, D, E and F (see chapter 8.1 “Delivery status” on page 59).
Deflector mirror
$ deflector mirror
$ 2 swivel mount brackets
Note
