Ordering information
12.5.2 Deflector mirror PNS 125 for protective field width 4 … 17 m (total)
Protective field height [mm] Type number Part number
300 PNS 125-034 1 019 425
450 PNS 125-049 1 019 426
600 PNS 125-064 1 019 427
750 PNS 125-079 1 019 428
900 PNS 125-094 1 019 429
1050 PNS 125-109 1 019 430
1200 PNS 125-124 1 019 431
1350 PNS 125-139 1 019 432
1500 PNS 125-154 1 019 433
1650 PNS 125-169 1 019 434
1800 PNS 125-184 1 019 435
Dimensional drawing see Fig. 44 on page 78. Effect on the scanning range see Tab. 7 on
page 24.
12.6 Accessories
Part Part number
C 4000-system connection
Hirschmann cable socket M26)×)11 + FE, crimp contacts, straight 6 020 757
Hirschmann cable socket M26)×)11 + FE, crimp contacts, angled 6 020 758
Terminal with 182 ' resistance for pin 9 and 10 on the system
connection (cf. page 47)
2 027 227
Connection cable
Plug straight/stripped, 2.5 m 2 022 544
Plug straight/stripped, 5 m 2 022 545
Plug straight/stripped, 7.5 m 2 022 546
Plug straight/stripped, 10 m 2 022 547
Plug straight/stripped, 15 m 2 022 548
Plug straight/stripped, 20 m 2 022 549
Plug straight/stripped, 30 m 2 022 550
Tab. 46: Part numbers
deflector mirror PNS 125
Tab. 4
: Part numbers
accessories
