Technical Data
DeviceNet
Cable socket M12, 5-pin, straight, shielded
360°-Shield on knurled nut, customizable, A-coded
Cable plug M12, 5-pin, straight, shielded
360°-shield on knurled nut, customizable, A-coded
Type: DOS-1205-GA Part no.: 6027534 Type: STE-1205-GA Part no.: 6027533
Cable socket M12, 5-pin, straight,
Cable 6 m, drop cable, A-coded
Connection cable 6 m, socket M12, 5-pin, straight, plug M12,
5-pin, straight, drop cable, A-coded, shield to pin 1
Type: DOL-1205-G06MK Part no.: 6028326 Type: DSL-1205-G06MK Part no.: 6028327
DeviceNet-T distributor socket M12, 5-pin, to plug, socket
7/8'', 5-pin
DeviceNet terminal resistor, socket 7/8'',
5-pin, straight
Type: SDO-02D78-SF Part no.: 6028330 Type: DOS-7805-GKEND Part no.: 6028329
1)
Minimum bending radius for
- Permanently laid cable: > 5 x cable diameter
- Flexibly laid cable: > 10 x cable diameter
