SICK DUSTHUNTER T User Manual

FLOWSIC100 Operating Instructions
Gas Velocity Monitor
Parts Overview
136 © SICK MAIHAK GmbH · Germany · All rights reserved 8012513/03-2008
6.1.3 Connection Cable
6.1.4 Control Unit MCU
6.1.5 Miscellaneous
Flange with tube D50SS200
Material VA, nominal length 200 mm
7042285
M, SA, SD
Flange with tube D50SS350
Material VA, nominal length 350 mm
7042286
Flange with tube D50S550
Material VA, nominal length 550 mm
7042287 M
Name Part number For FLSE100 type
Name Part number
Connection cable Master 7 core, length 5 m 2043678
Connection cable Master 7 core, length 10 m 2043679
Connection cable Slave 5 core, length 5 m 7042017
Connection cable Slave 5 core, length 10 m 7042018
Connection cable Slave 5 core, length 50 m 7042019
Name Part number
MCU-NWONN00000NN control unit in wall housing (orange),
Supply voltage 90 ... 250 V AC, without display
1040667
MCU-NWODN00000NN control unit in wall housing (orange),
Supply voltage 90 ... 250 V AC, with display
1040675
MCU-N2ONN00000NN control unit in wall housing (orange),
Supply voltage 24 V DC, without display
1040669
MCU-N2ODN00000NN control unit in wall housing (orange),
Supply voltage 24 V DC, with display
1040677
MCU-PWONN00000NN control unit in wall housing (orange),
Supply voltage 90 ... 250 V AC, with purge-air unit, without display
1040668
MCU-PWODN00000NN control unit in wall housing (orange),
Supply voltage 90 ... 259 V AC, with purge-air unit, with display
1040676
MCU-P2ONN00000NN control unit in wall housing (orange),
Supply voltage 24 V DC, with purge-air unit, without display
1040670
MCU-P2ODN00000NN control unit in wall housing (orange),
Supply voltage 24 V DC, with purge-air unit, with display
1040678
Name Part number
Purge-air hose DN 25, length 3 m 7047535
Purge-air hose DN 25, length 10 m 7047536
Connection box for connection cable 2046418
Damping set K100 2042503
