Operating Instructions GM35
Probe Model
Technical specifications, consumables and spare parts
8009389/07-2006 © SICK MAIHAK GmbH • Germany · All rights reserved 107
10.3 Consumables and spare parts
For information on ordering other spare parts, as well as prices and packaging units, please
contact your local sales partner.
10.3.1 Consumables for 2-Year Operation
10.3.2 Spare Parts of the SR Unit
Order No. Description
4 003 353 Optics cleaning cloth
5 306 091 Filter insert, micro top element
4 034 658 triple, gold coated for CO measuring chanal
Consumables for 2-year operation
Order No. Description
2 030 289 Measuring module CO, calibrated
2 030 290 Measuring module H
2
O/CO
2
, calibrated
2 023 540 Module IR source and Chopper
2 030 344 Power supply module
2 030 345 VIS sight module
6 022 360 Humidity sensor ambient air
2 023 550 Plug with cable for hygroclip connection
2 023 518 Swivel element reference filters
2 017 325 Swivel element ZPR (zero-point-reflector)
2 023 515 Motor with PCB (ZPR)
2 023 516 Frame for window, SRU front
2 023 513 N
2
O cell
2 023 448 Motor with PCB (reference filters)
2 017 339 Cover plate for internal optics, with heater pad
2 017 334 Hood for optical head housing
2 023 527 Plug connector, main power
2 020 020 CAN connector, male
2 020 432 CAN connector, female
2 024 027 Cable harness
2 023 799 Temperature sensor, housing heater control
2 029 931 Diffusion element
2 023 687 CAN bus cable evaluation unit – SR unit 3 x 2 x 0.74; 4 m long
2 023 688 Power cable SR unit or probe 3 x 1.5; 4 m long
2 023 704 CAN bus cable probe – SR unit 3 x 2 x 0.74, 0.6 m long
5 700 484 Cup spring
5 700 494 Washer
5 700 472 Nut self-locking M12
Spare parts SR unit
