GM35 Operating Instructions
Probe Model
Technical specifications, consumables and spare parts
112 © SICK MAIHAK GmbH • Germany · All rights reserved 8009389/07-2006
10.3.5 Spare parts for purge-air unit
10.3.6 Spare parts mMscellaneous
10.3.7 Securing material
Securing material: measuring probe–flange
Securing material: SR unit–measuring probe
6 020 400 Foil panel with display
2 017 329 Hinge pin
6 010 378 Lithium battery 3.00 V CR2032
Order No. Description
Ersatzteile Auswerteeinheit
Order No. Description
5 306 090 Air filter assembly, Europiclon
5 306 091 Filter insert, micro top element
4 708 971 Distributor 2xDN40
4 022 766 Purge-air hose DN40, length 5 m
5 700 520 Hose clamp DN40-60x12
Spare parts for purge-air unit
Order No. Description
2 023 688 Power supply cable for SR unit or probe, 4 m, 3 x 1.5
2
2 023 687 Connection cable evaluation unit – sensor, 4 m
2 023 704 CAN bus cable SR unit – probe, 0.6 m, 3 x 2 x0.75
2
Ersatzteile Diverse
Order No. Description
5 700 457 Screw, hexagon head, M16x60-A2
5 700 482 Washer, A17-A2
5 700 471 Nut, hexagon, M16 A2
5 700 480 Spring lock washer, A16
Securing material: measuring probe-flange
Order No. Description
5 700 484 Disk spring A25
5 700 472 Nut SSI M12
5 700 494 Spherical washer
2 017 329 Hinge bolt for GM35 flange attachment
4 023 743 Sealing tape
Securing material: SR unit-measuring probe
