2.3 Device features and configuration
2.3.1 Device features
The DUSTHUNTER T measuring system is available in three different device versions with
the following features:
Feature Device version
DUSTHUNTER T50 DUSTHUNTER T100 DUSTHUNTER T200
Active measuring path 0.5...2.5/2...5/4...8 m 0.5...2.5/2...5/4...12 m
Smallest measuring range
● Transmission 100...50%
● Opacity 0...50%
● Extinction 0...0.3
● Transmission 100...80%
● Opacity 0...20%
● Extinction 0...0.1
● Transmission 100...90%
● Opacity 0...10%
● Extinction 0...0.045
Zero point error ±0.8% transmission ±0.4% transmission ±0.2% transmission
Swivel error (at ±0.3°) 1% transmission 0.8% transmission 0.2% transmission
Contamination measurement
Limit values (transmission)
Without On one side with swivel plate in
sender/receiver unit
On both sides with swivel plate
None 20% for warning
30% for malfunction
30% for warning
40% for malfunction
Self-alignment None With
Display (on MCU) Option Standard
Analog output(s) 1 3 (2x with module)
Analog input(s) 2
Digital inputs 4
Relay outputs 5
