Operating instructions Distance sensors Dx35
Structure and function
18 © SICK AG • Subject to change without notice • 8014868/YEF7/2014-09-02
LEDs, teach-in
(continued)
LED Description
Q1 near, Q1 far,
Q2 near, Q2 far,
slow … fast
in expert mode
• "Q1 near" LED lights up and "slow … fast" LED ashes
cyclically: Select function for multifunctional input "MF".
– 1 x: Teach
– 2 x: Laser off
– 3 x: Inactive
• "Q1 far" LED lights up and "slow … fast" LED ashes
cyclically: Select level for multifunctional input "MF".
– 1 x: Low active
– 2 x: High active
• DT35 and DL35 models only
"Q2 near" LED lights up and "slow … fast" LED ashes
cyclically: Select output function for Q2.
– 1 x: 4 ... 20 mA
– 2 x: 0 ... 10 V
– 3 x: Switching
Table 4: LEDs, teach-in
Control elements
Control element Description
select (–) • In run mode
Press and hold select pushbutton longer than 5 sec-
onds: Enter or leave teach mode.
• In teach mode
Press select pushbutton: Select function.
• In ne teach mode
Move previously taught-in switching point by –10 mm.
set (+) • In run mode (IR models only)
Press and hold set pushbutton longer than 5 seconds:
Enter or leave alignment mode.
• In teach mode
Press set pushbutton: Perform teach, select function.
• In ne teach mode
Move previously taught-in switching point by +10 mm.
select + set • In run mode
Press and hold select and set pushbuttons simultane-
ously for longer than 10 seconds: Enter or leave expert
mode.
• In teach mode
After previously performing teach, press select and set
pushbuttons simultaneously for less than 1 second:
Enter or leave ne teach.
Table 5: Control elements
