Operating instructions Distance sensors Dx35
Technical data
3) DT35-Bxxxxx, DS35-Bxxxxx: At 6 % … 90 % remission
DL35-Bxxxxx, DR35-Bxxxxx: on "diamond grade" reective tape
4) Depends on the congured speed "super-slow" … "super-fast"
5) Continuous change of the distance from the object in the measuring range
6) Lateral entry of the object into the measuring range
Table 21: Performance data
Output rate, response time, and switching frequency as a function of the speed setting
All Dx35 except for DT35-B15551 and DS35-B15521
Super-fast Fast Medium Slow Super-slow
Output rate 1 ms 2 ms 4 ms 8 ms 32 ms
Response time 2.5 ms 6.5 ms 12.5 ms 24.5 ms 96.5 ms
Switching
frequency
333 Hz 100 Hz 50 Hz 25 Hz 6 Hz
DT35-B15551 and DS35-B15521
Super-fast Fast Medium Slow Super-slow
Output rate 2 ms 4 ms 8 ms 16 ms 64 ms
Response time 4.5 ms 12.5 ms 24.5 ms 48.5 ms 192.5 ms
Switching
frequency
166 Hz 50 Hz 25 Hz 12 Hz 3 Hz
Table 22: Overview of output rate, response time, and switching frequency
13.4 Power supply
Supply voltage V
S
1)
• 12 V DC … 30 V DC
• 18 V DC … 30 V DC (when using IO-Link)
• DT35-Bxxxxx, DL-Bxxxxx: 13 V DC ... 30 V DC
(when using the analog voltage output)
Power consumption
2)
≤ 1.7 W
Residual ripple
3)
< 5 V
SS
1) Limit values, reverse-polarity protected operation in short-circuit protected network: max. 8 A
2) At 20 °C and without load
3) May not fall short of or exceed V
S
tolerances
Table 23: Power supply
13.5 Inputs
Multifunctional input (MF)
1)
1 x
→ See Page 36, Chapter 8.5
1) Response time: ≤ 60 ms
Table 24: Inputs
