8014868/YEF7/2014-09-02 • © SICK AG • Subject to change without notice 57
Operating instructions Distance sensors Dx35
Technical data
13.9 Mechanics
Dimensions → See Page 53, Chapter 13.1.
Weight 65 g
Housing material • Housing: plastic (ABS and PC)
• Front screen: acrylic glass (PMMA)
Connection type Male connector M12, 5-pin
Indication LEDs
→ See Page 53, Chapter 13.1.
Table 28: Structural design
13.10 "Repeatability" diagrams
13.10.1 DT35 and DS35 models
Characteristic curve for "super-slow" speed Characteristic curve for "slow" speed
Super Slow
Distance in m (feet)
14
01
0
12
(46)
(6.6) (13.1)
(19.7) (26.3) (32.8)
(39.4)
Repeatabilty in mm (inch
)
0
2
(0.08)
4
(0.16)
6
(0.24)
8
(0.31)
10
(0.39)
12
(0.47)
2468
Functional reserve
Specification basis
technical data
Secured performance
90 % Remission
18 % Remission
6 % Remission
Distance in m (feet)
14
01
0
12
(46)
(6.6) (13.1)
(19.7) (26.3) (32.8)
(39.4)
Repeatability in mm (inch
)
0
2
(0.08)
4
(0.16)
6
(0.24)
8
(0.31)
10
(0.39)
12
(0.47)
Slow
2468
Functional
reserve
Specification basis
technical data
Secured
performance
90 % Remission
18 % Remission
6 % Remission
Fig. 19: Characteristic curve for "super-slow" speed Fig. 20: Characteristic curve for "slow" speed
