8014868/YEF7/2014-09-02 • © SICK AG • Subject to change without notice 45
Operating instructions Distance sensors Dx35
IO-Link interface
9.3.4 SICK-specic–teach
Index
decimal
(hex)
Description Format Access Value range Example Remarks
130 (0x82) TEACH UNIT16 W 0: Q1 DtO
(Q1 distance to
object)
1: Q2 DtO
(Q2 distance to
object)
2: Q1 near
3: Q1 far
4: Q1 centering
5: Q2 near
6: Q2 far
7: Q2 centering
8: Q1 ObSB
(Q1 object between
sensor and
background)
9: Q2 ObSB
(Q2 object between
sensor and
background)
10: Q2 4 mA
11: Q2 20 mA
12: Q2 0 V
13: Q2 10 V
14: Q2 Analog
centering
15: Fine teach
+10 mm
16: Fine teach
-10 mm
A teach overwrites
a function that has
already been set
with a newly selected
function. For values
that are not taught
in again and for an
unsuccessful teach,
the old value is
retained.
1) SICK-specic service data – teach
9.3.5 SICK-specic–processdata
Index
decimal
(hex)
Description Format Access Value range Example Remarks
83 (0x53) Process data
structure
UINT8 R/W 0: Distance+Q1+Q2
1: Distance+VMA
+alarm
2:Level+VMA+alarm
3: Distance
4: Distance+
signal quality
3
Page 39,
Chapter 9.2.
105 (0x69) Process data
resolution
UINT8 R/W 0: 0.1 mm
1: 1 mm
2: 10 mm
Resolution distance
measurement value
for the process data
(IO-Link only)
