Operating instructions Distance sensors Dx35
IO-Link interface
44 © SICK AG • Subject to change without notice • 8014868/YEF7/2014-09-02
Index
decimal
(hex)
Description Format Access Value range Example Remarks
66 (0x42) Bit lter for switch-
ing output(s)
UINT8 R/W • 0: OFF
• 2: Filter depth 2
• 4: Filter depth 4
• 8: Filter depth 8
• 16: Filter depth 16
Filter depth 4:
Four consecutive
measurement
values must
exceed or fall
below the
congured
switching point
in order for the
switching output
to react.
Denes how often the
switching requirement
(e.g. exceed switching
point Q1 far) has
to be fullled in
succession before
the switching output
changes its status.
The bit lter affects
only the switching
output behavior, not
the process data and
analog output.
Writable only if
"0: Expert" was
selected for index
"103".
1) SICK-specic service data – sensor performance
