Operating instructions Distance sensors Dx35
Commissioning
8.6 Reset to factory setting
1. Switch off the supply voltage.
2. Press an hold the select pushbutton.
3. Hold down the select pushbutton and switch on the supply voltage.
4. When all teach LEDs ash, release the select pushbutton.
All settings have been reset to the factory setting.
8.7 External teach functions
NOTE
You can activate or deactivate a conrmation function,
which provides a feedback about the accomplishment
of an external teach. This teach conrmation can be
activated via IO-Link or the multifunctional input MF. The
feedback is provided via Q1. → See Page 50, Chap-
ter 10.4.
You can perform an external teach by applying a signal to the
multifunctional input MF. The "external teach" option for the multifunctional
input MF must be selected via expert mode. → See Page 36,
Chapter 8.5.
The timing tolerance for the two "Move last teach point" functions is
± 20 ms. The timing tolerance is ± 30 ms for the other teach functions.
Overview of external teach functions
(continued on next page)
Teach function Time [ms]
Move last teach point + 10 mm 60
Move last teach point – 10 mm 120
Switch off laser 200
Switch on laser 300
Teach in Q1 distance to object 400
Teach in inverted behavior for Q1 distance to object 500
Teach in Q1 near for window 600
Teach in Q1 far for window 700
Teach in Q1 object between sensor and background 800
Teach in Q1 window centering
1), 2)
900
Teach in Q2 distance to object 1000
Teach in inverted behavior for Q2 distance to object 1100
Teach in Q2 near for window 1200
Teach in Q2 far for window 1300
