14.3 Reectorplateandreectivetape
NOTE
Only for DL35 and DR35 models or as an alignment aid
for the infrared light models.
14.3.1 Reectorplate
4
(0.16)
Ø 6.5 (0.26)
294
(11.57)
330
(12.99)
330 (12.99)
294 (11.57)
25
(0.98)
280
(11.02)
25 (0.98)
280
(11.02)
Fig. 30: Reector plate
Description Type Order No.
Reector plate, "diamond grade" reective tape,
330 mm x 330 mm, base plate material: aluminum,
screw connection
PL240DG 1017910
14.3.2 Reectivetape
Fig. 31: Reective tape
Description Type Order No.
"Diamond grade" reective tape, self-adhesive, can be
assembled from the sheet
REF-DG-K 4019634
14.4 IO-Link master
Description Type Order No.
IO-Link master IOLSHPB-P3104R01 6039728
