8014868/YEF7/2014-09-02 • © SICK AG • Subject to change without notice 43
Operating instructions Distance sensors Dx35
IO-Link interface
Index
decimal
(hex)
Description Format Access Value range Example Remarks
97 (0x61) Timer function for
switching out-
put(s)
UINT8 R/W • 0: Disabled
(deactivated)
• 1: ON delay
• 2: OFF delay
• 3: ON/OFF delay
• 4: One-shot
98 (0x62) Time for timer
function
UINT8 R/W 0 … 255 ms In 1 ms steps
Table 15: SICK-specic service data – outputs
9.3.3 SICK-specic–sensorperformance
Index
decimal
(hex)
Description Format Access Value range Example Remarks
103 (0x67) Response time UINT8 R/W • 0: Expert
• 1: Super-slow
• 2: Slow
• 3: Medium
• 4: Fast
• 5: Super-fast
2 Indexes 64, 67, and
66 available only if "0:
Expert" was selected
here.
64 (0x40) Integration time of
the measurement
or output rate
UINT8 R/W • 0
• 1
• 2
• 3
• 4
• 5
• 6
• 7
• 8
DT35 and DS35 red
laser, class 1 devices:
Integration time of
the measurement or
output rate 2
n
* 2 ms,
All other devices:
Integration time of
the measurement or
output rate 2
n
* 1 ms
Writable only if
"0: Expert" was
selected for index
"103".
67 (0x43) Averaging UINT8 R/W • 1: OFF
• 2: Filter depth 2
• 4: Filter depth 4
• 8: Filter depth 8
• 16: Filter depth 16
Sliding averaging
over x measurement
values. Affects only
process data and
analog output, not the
switching behavior.
Writable only if
"0: Expert" was
selected for index
"103".
