Operating instructions Distance sensors Dx35
Commissioning
36 © SICK AG • Subject to change without notice • 8014868/YEF7/2014-09-02
8.5 Expert mode
Use expert mode to set the following functions:
• Function for multifunctional input MF:
External teach (factory setting), laser off, multifunctional input MF inac-
tive
• Level for multifunctional input MF:
High active (factory setting), Low active
• For DT35/DL35 distance sensors:
Output behavior for output Q2:
4 … 20 mA (factory setting), 0 … 10 V, switching output Q2
Description Active LED LED slow … fast
Function for
multifunctional
input MF
Q1 near • LED slow … fast ashes 1 x:
external teach
• LED slow … fast ashes 2 x:
laser off
• LED slow … fast ashes 3 x:
multifunctional input MF inactive
Level for
multifunctional
input MF
Q1 far • LED slow … fast ashes 1 x:
low active
• LED slow … fast ashes 2 x:
high active
Output behavior
for Q2 output
1)
Q2 near • LED slow … fast ashes 1 x: 4 ...
20 mA
• LED slow … fast ashes 2 x: 0 …
10 V
• LED slow … fast ashes 3 x: Switch-
ing output
1) For DT35/DL35 distance sensors only
Table 8: Overview of expert mode
Output: The Q2 output is to be set to 0 … 10 V.
1. From operating mode only: Press and hold select and set pushbuttons
simultaneously for longer than 10 seconds. The Q1 near LED lights up
and the LED slow … fast ashes cyclically according to the previous
setting.
2. Press repeatedly the pushbutton until the LED Q2 near lights up.
3. Press repeatedly the set pushbutton until the desired option has been
set.
• LED slow … fast ashes 1 x: 4 … 20 mA
• LED slow … fast ashes 2 x: 0 … 10 V
• LED slow … fast ashes 3 x: switching output.
4. To leave expert mode, press and hold the select and set pushbuttons
simultaneously for longer than 10 seconds or wait 5 minutes without
pressing the pushbuttons.
