SICK Dx35 - Universal bar clamp systems

8014868/YEF7/2014-09-02 • © SICK AG • Subject to change without notice 63
Operating instructions Distance sensors Dx35
Accessories
14.2.3 Universal bar clamp systems
59.5
(2.34)
43
(1.69)
24
(0.94)
90
(3.54)
42
(1.65)
43
(1.69)
Fig. 29: Left: Plate N02 for universal clamps
Right: Plate N03 for universal clamps
Description Type Order No.
Plate N02 for universal clamps, mounting materials BEF-KHS-N02 2051608
Plate N02N for universal clamps, mounting materials BEF-KHS-N02N 2051618
Plate N03 for universal clamps, mounting materials BEF-KHS-N03 2051609
Plate N03N for universal clamps, mounting materials BEF-KHS-N03N 2051619
