Operating instructions Distance sensors Dx35
IO-Link interface
46 © SICK AG • Subject to change without notice • 8014868/YEF7/2014-09-02
Index
decimal
(hex)
Description Format Access Value range Example Remarks
107 (0x6B) Process data
normalization
UINT16 R/W • 0 … 50000 mm Move process data
zero point in 1 mm
steps.
Table 16: SICK-specic service data – process data
9.3.6 SICK-specic–othersettings
Index
decimal
(hex)
Description Format Access Value range Example Remarks
81 (0x51) Multifunctional
input MF function
UINT8 R/W • 0: Teach
• 1: Laser on/off
• 2: MF OFF
(MF deactivated)
1
99 (0x63) Multifunctional
input MF level
(bit 0)
Multifunctional
input MF teach
conrmation on
Q1 (bit 1)
Record R/W Bit 0:
• 0: Low active
• 1: High active
Bit 1:
• 0: Inactive
• 1: Active
→ See Page 48,
Chapter 10.1
and Page 49,
Chapter 10.2.
104 (0x68) Alarm function
(bit 0)
UINT8 R/W • 0: Clamp
(zero-value output)
• 1: Hold
Select behavior for
the sensor if no
measurement is
possible.
• Clamp: The sensor
outputs "0".
• Hold: The last valid
measurement value
is retained.
Note Do not set "hold"
option for ObSB mode.
→ See Page 49,
Chapter 10.2.
82 (0x52) Pushbutton lock UINT8 R/W • 0: Switch OFF
• 1: Switch ON
0
68 (0x44) Laser on/off UINT8 R/W • 0: Switch OFF
• 1: Switch ON
1 –
Table 17: SICK-specic service data – other settings
