Operating instructions Distance sensors Dx35
Accessories
62 © SICK AG • Subject to change without notice • 8014868/YEF7/2014-09-02
14.2.2 Alignment bracket
50.5 (1.99)
90 (3.54)
4.8 (0.19)
93 (3.66)
6 (0.24)
13 (0.51)
6
(0.24)
16
(0.63)
4 (0.16)
5.9 (0.23)
54 (2.13)
7 (0.28)
5 (0.20)
50.5 (1.99)
99 (3.90)
38 (1.50)
12
(0.47)
56.5 (2.22)
37.5 (1.48)
5 (0.20)
25
(0.98)
46 (1.81)
44.5 (1.75)
5 (0.20)
16.4 (0.65)
Fig. 28: Alignment bracket
Description Type Order No.
Alignment bracket, steel, zinc-coated, incl. mounting
hardware for the sensor
BEF-AH-DX50 2048397
