SICK Dx35 User Manual

Operating instructions Distance sensors Dx35
IO-Link interface
42 © SICK AG • Subject to change without notice • 8014868/YEF7/2014-09-02
Index
decimal
(hex)
Description Format Access Value range Example Remarks
74 (0x4A) Q2 switching
function
UINT8 R/W • 0: DtO
(Distance to
Object)
• 1: ObSB (Object
between Sensor
and Background)
• 2: Window
• 3: VMA (signal level
warning)
• 4: Alarm
(fault output)
DS35/DR35: 0
DT35/DL35:–
→ See Page 27,
Chapter 8, Page 48,
Chapter 10.1
and Page 49,
Chapter 10.2.
75 (0x4B) Q2 switching point
near
UINT16 R/W 50 … 50000 mm – In 1 mm steps
77 (0x4D) Q2 switching point
far
UINT16 R/W 50 … 50000 mm DT35/DL35: –
DS35: 10000
DR35: 35000
In 1 mm steps
76 (0x4C) Q2 hysteresis near UINT16 R/W 0 … 49550 mm 25 In 1 mm steps
78 (0x4E) Q2 hysteresis far UINT16 R/W 0 … 49550 mm 25 In 1 mm steps
95 (0x5F) Q2 near-far center-
ing
UINT16 R/W 50 … 50000 mm – In 1 mm steps
79 (0x4F) Q2 analog near UINT16 R/W 50 … 50000 mm DT35: 50
DL35: 200
DS35/DR35: –
In 1 mm steps
80 (0x50) Q2 analog far UINT16 R/W 50 … 50000 mm DT35: 10000
DL35: 35000
DS35/DR35: –
In 1 mm steps
96 (0x60) Q2 analog near-far
centering
UINT16 R/W 50 … 50000 mm DT35: 5025
DL35: 17600
DS35/DR35: –
In 1 mm steps
93 (0x5D) Q2 Signal level
warning (VMA)
threshold
UINT16 R/W 0 … 65535 –
→ See Page 48,
Chapter 10.1
and Page 49,
Chapter 10.2.
65 (0x41) Q1/Q2 inversion Record R/W • 0: Q1 and Q2 not
inverted
• 1: Only Q1 inverted
• 2: Only Q2 inverted
• 3: Q1 and Q2
inverted
Bit 0: Q1
Bit 1: Q2
Bit 2 … 7: reserved
106 (0x6A) Distance offset UINT16 R/W 0 … 50000 In 1 mm steps
