1...3 sec.
2
3
1
Figure 27: WTB4F, adjustment of the sensing range using a teach-turn adjustment
WTB4FT/WTB4FA-xxxxxx3x
Adjustment via teach-in: The sensing range is adjusted by pressing the teach-in button
(approx. 1-3 sec.).
WTB4FT/WTB4FA-xxxxxxAx
Sensor with fixed sensing range and no adjustment.
COMMISSIONING
6
