Introduction
1.1 Service&Support
3UG4 / 3RR2 monitoring relays
12 Manual, 05/2016, NEB927043002000/RS-AC/004
Product Support
Are you looking for product information such as technical data, updates or FAQs? Here, the
"Product Support" section of the Service & Support Portal offers an extensive collection of all
information about the Siemens Industry Automation and Drive Technologies products and
solutions:
Answers to frequently asked questions (FAQs)
Updates/upgrades, service packs and support tools for downloading
Manuals and operating instructions
Technical data/CAx data
Approvals and certificates
Test certificates and characteristic curves
All Product Support information is at your disposal free of charge and around the clock, and
you always get the current version.
Link:
Product Support (http://support.automation.siemens.com/WW/view/en/4000024)
CAx data
The CAx Download Manager provides you with a simple means of gaining access to up-to-
date product data for your CAx or CAe system.
You configure your own download package with just a few clicks. You can choose from the
following information for products
Product images
2D dimensional drawings
3D models
Internal circuit diagrams
EPLAN macro files
Manuals
Characteristics
Operating instructions
Certificates
Product master data
Link:
CAx Download Manager
(http://support.automation.siemens.com/WW/view/en/42455541)
