Siemens 3UG4 - Functions

3UG4.1 line monitoring relay
6.6 3UG4615 / 3UG4616 line monitoring relays
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
143
6.6.2
Functions
General functionality
The 3UG4615 line monitoring relays monitor a three-phase system for
phase failure
,
undervoltage
,
overvoltage
, and
phase sequence
.
Note
The 3UG4616 line monitoring relays have the same functions as the 3UG4615 monitoring
relays and also monitor the neutral conductor for failure
.
The devices feature a wide-range voltage input and are
self-powered
(measuring voltage
= rated control supply voltage). Depending on the version, the line monitoring relays are
powered with a line-to-line voltage of 160 to 690 V (3UG4615) or with a line-to-neutral
voltage of 90 to 400 V (3UG4616) through terminals L1 / L2 / L3.
The 3UG4615 / 3UG4616 line monitoring relays feature 2 output relays (output relay K1 and
output relay K2).
The 3UG4615 / 3UG4616 line monitoring relays have a display and are parameterized with
three keys.
You will find the setting ranges and factory settings of the available parameters in Chapter
"Operation (Page 146)."
You will find a description of the individual parameters in Chapter "Parameters (Page 363)."
Note
The specified voltages represent the absolute thresholds.
