3UG4.1 line monitoring relay
6.6 3UG4615 / 3UG4616 line monitoring relays
3UG4 / 3RR2 monitoring relays
154 Manual, 05/2016, NEB927043002000/RS-AC/004
Mechanical design
3UG4615-1....
3UG4616-1....
3UG4615-2....
3UG4616-2....
Width
mm
22.5
Height
mm
92
102
94
103
Depth
mm
91
Built in orientation
any
Distance, to be maintained,
to earthed part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained,
to the ranks assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained,
conductive elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
