3UG4.1 line monitoring relay
6.7 3UG4617 / 3UG4618 line monitoring relays
3UG4 / 3RR2 monitoring relays
170 Manual, 05/2016, NEB927043002000/RS-AC/004
Mechanical design
3UG4617-1....
3UG4618-1....
3UG4617-2....
3UG4618-2....
Width
mm
22.5
Height
mm
92
102
94
103
Depth
mm
91
Built in orientation
any
Distance, to be maintained,
to earthed part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained,
to the ranks assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained,
conductive elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
