3UG4621/3UG4622 current monitoring relays
7.7 Technical data
3UG4 / 3RR2 monitoring relays
188 Manual, 05/2016, NEB927043002000/RS-AC/004
Mechanical design
3UG4621-1....
3UG4622-1....
3UG4621-2....
3UG4622-2....
Width
mm
22.5
Height
mm
92
94
Depth
mm
91
Built in orientation
any
Distance, to be maintained, to
earthed part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, to
the ranks assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained,
conductive elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
