3UG458. insulation monitoring relay
3UG4 / 3RR2 monitoring relays
214 Manual, 05/2016, NEB927043002000/RS-AC/004
The insulation monitoring relays monitor the following fault types, depending on the version:
● Open circuit
● Incorrect settings
● Ungrounded, strictly AC systems for insulation faults
● Ungrounded, strictly DC systems for insulation faults
● Ungrounded, mixed DC systems and AC systems for insulation faults (e.g. AC systems
with rectifiers or switched-mode power supplies)
Note
The use of two 3UG458
devices in a galvanically connected area (monitored area) is not
