3UG463. voltage monitoring relay
10.7 Technical data
3UG4 / 3RR2 monitoring relays
286 Manual, 05/2016, NEB927043002000/RS-AC/004
3UG463.-1.A
3UG463.-1.L
3UG463.-1.W
3UG463.-2.A
3UG463.-2.L
3UG463.-2.W
Impulse voltage
resistance
rated
value
kV 4
Recorded real
power
W 2
Protection class IP
IP20
Electromagnetic
compatibility
IEC 60947-1 / IEC 61000-6-2 / IEC 61000-6-4
Operating current
at
17 V minimum
mA 5
Continuous current
of the DIAZED fuse
link of the output
relay
A 4
Resistance against
vibration
according
to IEC 60068-2-6
1 … 6 Hz: 15 mm, 6 … 500 Hz: 2g
Resistance against
shock
according to
IEC 60068-2-27
sinusoidal half-wave 15g / 11 ms
Installation altitude
at a height over
sea level
maximum
m
2 000
Maximum permissible
voltage for safe
disconnection
• between control
and auxiliary
circuit
V
300
• between auxiliary
circuit and
auxiliary circuit
V 300
Conductor-bound
parasitic coupling
BURST
according to
IEC 61000-4-4
2 kV
Conductor-bound
parasitic coupling
conductor-earth
SURGE
according
to IEC 61000-4-5
2 kV
Conductor-bound
parasitic coupling
conductor-conductor
SURGE
according
to IEC 61000-4-5
1 kV
Electrostatic
discharge
according
to IEC 61000-4-2
6 kV contact discharge / 8 kV air discharge
