3UG4641 cos phi and active current monitoring relay
11.7 Technical data
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
305
Mechanical design
3UG4641-1....
3UG4641-2....
Width
mm
22.5
Height
mm
102
103
Depth
mm
91
Built in orientation
any
Distance, to be maintained, to earthed part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, to the ranks
assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, conductive elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Type of mounting
snap-on mounting
Product function
removable terminal for auxiliary
and control circuit
Yes
