Siemens 3UG4 - Page 321

3UG4651 speed monitoring relay
12.7 Technical data
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
321
Mechanical design
3UG4651-1....
3UG4651-2....
Width
mm
22.5
Height
mm
86
Depth
mm
102
103
Built in orientation
any
Distance, to be maintained, to earthed part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, to the ranks
assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, conductive elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
