Accessories
13.2 Accessories for 3UG4 monitoring relays
3UG4 / 3RR2 monitoring relays
330 Manual, 05/2016, NEB927043002000/RS-AC/004
3UG3207-2B two-pole bow electrode
Because of the small space requirement on side installation, the 3UG3207-2B two-pole bow
electrode for leakage monitoring and level monitoring can be used in small vessels and
tubes. The probe can also be used to warn of the ingress of water into a casing.
Image 13-3 3UG3207-2B two-pole bow electrode
3UG3207-1B single-pole bow electrode for side mounting
The 3UG3207-1B single-pole bow electrode for side mounting can also be used as a max.
value electrode or for alarming in conductive tanks or tubes.
Image 13-4 3UG3207-1B single-pole bow electrode
3UG3207-1C single-pole rod electrode for side mounting
The 3UG3207-1C single-pole rod electrode for side mounting can be used to monitor high
flow velocities
Image 13-5 3UG3207-1C single-pole rod electrode
