Starting the ON-delay time via IO-Link
The ON-delay time can also be started through the process image of the outputs (PIQ) by
setting the control command "Start ON delay time." This is a simple method of permitting
brief load steps during operation if these are predictable.
The ON-delay time can be set either locally via the three keys on the device, or via IO-Link.
The requirements governing the starting of the ON-delay time (Power-ON, manual reset
and/or restart) can only be modified via IO-Link.
Note
After exiting the menu level SET, the ON
-delay time starts again.
Start of the ON-delay
The following table shows the behavior of the ON-delay time (onDel) with the device variants
3UG4 monitoring relay and 3RR2 current monitoring relay.
Device variants
Start of the ON-delay possible for:
"Power-ON"
Automatic reset
Manual reset
3RR21
Yes
Yes
Yes
3RR22
Yes
Yes
Yes
3UG4614
Yes
No
No
3UG4621 / 3UG4622
Yes
Yes
Yes
3UG4624
Yes
No
No
3UG4625
Yes
No
Yes
3UG4633
Yes
No
No
3UG4641
Yes
1)
Yes
1)
Yes
1)
3UG4651
Yes
No
No
1)
Setting: I
res
▼ = OFF
You will find further information on the ON-delay time in the "Functionality" chapter for each
monitoring relay.
Possible indications on the display:
onDel
