3UG4501 filling level monitoring relay
5.7 Technical data
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
99
Mechanical design
3UG4501-1....
3UG4501-2....
Width
mm
22.5
Height
mm
92
94
Depth
mm
91
mounting position
any
Distance, to be maintained, to earthed part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, to the ranks
assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be maintained, conductive
elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Mounting type
screw and snap-on mounting
Product function
removable terminal for
auxiliary and control circuit
Yes
