Siemens 7MF4233 series

UMSITRAPDS3-1 Model Designations and Specifications
November 2005
9-3
Other versions
Add "-Z" to order number and add short spec…
7MF4033 - . . . . . - . . . . - Z
Transmitter with mounting bracket of:
- steel
A01
- stainless steel
A02
Han 7D plug (metal, gray)
3)
A30
Han 8U plug (instead of Han 7D)
3)
A31
Labeling of rating plate (instead of German):
- English
B11
- French
B12
- Spanish
B13
- Italian
B14
Manufacturer test certificate M acc. to DIN 55 350, part 18, and
according to ISO 8402
C11
Acceptance test certificate B acc. to DIN 50 049 / EN 10 204-3.1 B
C12
Works certificate according to DIN 50 049-2.2 / EN 10 204-2.2
C14
Setting upper output signal limit to 22.0 mA
D05
Acid gas version according to NACE; only with Hastelloy
process diaphragm
D07
IP 68 (not with Han 7D/Han 8U plug, cable screwed gland Pg13.5 and
measuring cells < 914 psi)
D12
Application in zone 0 (basic device EEx ia)
3)
E02
Oxygen application (in oxygen measurement and
Inert filling liquid: 2325 psi maximum)
E10
Range to be set, specify in clear text:
Y01: ... to ... mbar, psi, kPa, MPa, ... (27 characters maximum)
Y01
Tag number / description
(16 characters maximum) specify in clear text:
Y15
Tag message (27 characters maximum) specify in clear text:
Y16
Setting digital display, specify in clear text: mbar, psi, kPa, MPa, ...
Y20
Factory pre-settings other than "Y01", "Y20" and "D05" are not possible.
Notes:
1)
Without cable screwed gland
3)
Not FM approved
2)
Not for "explosion proof" protection
Scope of delivery:
Transmitter as ordered, 1 brief instruction (Leporello)
Ordering example:
Position line: 7MF4033-1EA00-1AA6-Z
B-line: A01+Y01+Y20
C-line: Y01: 145 to 290 psi
C-line: Y20+D100+D36: psi
