9.4 MEASURING SPANS AND OVERLOAD LIMITS
This section provides tables that contain the measuring spans and overload limits for each series DSIII
transmitter.
TABLE 9-17 Pressure Transmitter, 7MF4033
Process Pressure Limits
Measuring Span, Continuously Adjustable
Lower Upper
0.15 To 14.5 psi -14.5 psi 87 psi
0.58 To 60 psi -14.5 psi 145 psi
2.3 To 230 psi -14.5 psi 464 psi
9.1 To 925 psi -14.5 psi 1450 psi
23 To 2325 psi -14.5 psi 3625 psi
1)
58 To 5800 psi
1)
-14.5 psi 8700 psi
1)
1) For oxygen measurement, maximum is 2325 psi.
TABLE 9-18 Differential Pressure and Flow Transmitters, 7MF4433 & 7MF4533
Maximum Working Pressure
Measuring Span, Continuously Adjustable
7MF4433 7MF4533
0.4 To 8 inH
2
O 470 psi
4)
470 psi
4)
0.4 To 24 inH
2
O 2300 psi 2300 psi
1 To 100 inH
2
O 2300 psi 6090 psi
2.4 To 240 inH
2
O 2300 psi 6090 psi
6.4 To 640 inH
2
O 2300 psi 6090 psi
4.3 To 435 psi 2300 psi 6090 psi
1), 2), 3)
1) For oxygen measurement, maximum is 2325 psi
2) Silicon measuring cell fill only
3) MWP 4568 psi with stainless steel process flange screw
4) Not suitable for remote process mounting
TABLE 9-19 Absolute Pressure, Gauge Construction, 7MF4233
Measuring Span, Continuously Adjustable Process Pressure Limit
3.3 To 100 inH
2
O see Note 87 psi
18 To 525 inH
2
O 145 psi
64 To 2000 inH
2
O 435 psi
400 To 12,000 inH
2
O 1450 psi
Note: 100 inH
2
O Cell
This measuring cell is designed for operation within the measuring limits of 0
inH
2
O (absolute) to 100 inH
2
O (absolute). When stored in the normal ambient
pressure of about of about 14.7 psi (absolute), the measuring cell is in the
overload state. An overload error of up to 0.8 inH
2
O may occur. The overload
disappears in normal operation within the measuring limits and the transmitter
operates within specifications.
When performing accurate continuous pressure measurements within the
measuring limits, a readjustment of the transmitter zero for absolute pressure
must be performed after approximately one day (refer to Section 6.2.5).
