Siemens 7MF4233 series

UMSITRPDS3-1 Model 275 Universal Hart Communicator
November 2005
2-19
1 Device setup* 1 Process variables 1 Pressure +
2 Percent range +
3 Analog output +
4 Sensor temperature +
2 Diagnostics and 1 Diagnosis 1 Min / max pointer >
service 2 Operating hours >
3 Warnings / alarms >
4 Status >
2 Simulation / Test 1 Simulation 1 Loop Test
2 Inputs >
2 Test 1 Self Test
2 Master reset
3 Control modes 1 Local keys ctrl mode
2 Write protect (status)
3 Set write protect
4 Trim 1 Position correction
2 Sensor trim >
3 Trim analog output >
5 Restore manufacturers 1 All trims
trims 2 DAC trims
3 Position correction
4 Sensor trim >
6 All measured values 1 Pressure +
2 Raw value
3 Sensor Temp +
4 El Temp +
5 AO +
3 Basic setup 1 Tag
2 Unit
3 Position correction
4 LRV
5 URV
6 Damp
7 Transfer function
4 Detailed setup 1 Sensors 1 Pressure sensor 1 Pressure +
2 Unit
2 Temperature sensor 1 Sensor temperature +
2 El temperature +
2 Signal condition 1 Process variables >
2 Position correction
3 Zero / span set >
4 Damping
5 Transfer function
6 Measuring speed
3 Output condition 1 Analog output +
2 HART output > Polling address and number of preambs
4 Device information 1 Ranges and limits > Module range, pressure USL and LSL,
and minimum span
2 Common device
information >
Manufacturer, model, measurement type,
etc.
3 Sensor information > Process connection, flange type, etc.
4 Remote seal > Seal type, material, fill, etc.
5 Local meter > Type, engineering units, bargraph
activation.
6 Revision numbers > Universal; field device DD,
software/firmware, and hardware.
5 Reviews > Step thru configuration
2 PV Notes: * = Reached from the Online menu by pressing 3 Device setup
3 AO > = Press to access lower level menu(s) not shown
4 LRV + = Active data displayed
5 URV HART Communicator, Rev 5
FIGURE 2-5 SITRANS P Online Menu Map
