Installation UMSITRPDS3-1
November 2005
4-10
4.3.4 Transmitter Operating Mode and Network Type
A transmitter outputs either an analog current or an equivalent digital signal, depending upon the selected
operating mode. The operating mode also determines the type of network (Point-to-Point or Multi-Drop)
to be installed, as shown in Table 4-1 and the following subsections.
TABLE 4-1 Operating Mode and Network
OPERATING MODE NETWORK TYPE NETWORK FIGURE(S)
Analog Point-to-Point 4-6, 4-7, and 4-8
Digital Multi-Drop 4-9
4.3.4.1 Analog Mode
When a transmitter is configured for analog mode operation, the following statements apply.
The transmitter outputs a 4-20 mA signal for input to devices such as controllers and recorders.
A Point-to-Point network is used comprising a transmitter, Primary/Secondary Master, and other non-
signaling devices. The transmitter polling address is 0 (zero).
Point-to-Point networks are shown in Figures 4-6, 4-7, and 4-8.
The optional display can be used for local indication of transmitter output.
Each transmitter is factory configured for analog mode unless otherwise ordered. The polling address
is set to zero (0).
A Model 275 HART Communicator is used for configuration, diagnostics, and reporting the current
process variable.
Note: If using a Model 375 Field Communicator, see the inside of the front
cover of this manual.
