Model 275 Universal Hart Communicator UMSITRPDS3-1
November 2005
2-20
1 Device setup 1 Process variables 1 Preset variable
2 Percent range
3 Analog output
2 Diagnostics and 1 Test device 1 Self test
service 2 Status
2 Loop test
3 Calibration 1 Rerange 1 Keypad input
2 Apply values
2 Trim analog output 1 D/A trim
2 Scaled D/A trim
3 Sensor trim
3 Basic setup 1 Tag
2 Unit
3 Range values
4 Device information 1 Date
2 Descriptor
3 Message
4 Write protect
5 Meter type
5 Transfer function
6 Damping
4 Detailed setup 1 Sensors 1 Process variables
2 Sensor service 1 Sensor trim
2 Characterize
3 Unit
2 Signal condition 1 Process variables
2 Range values
3 Unit
4 Transfer Function
5 Damping
3 Output condition 1 Process variables 1 Loop test
2 D/A trim
3 Scaled D/A trim
2 Analog output
3 AO alarm type
4 HART output 1 Poll address
2 Number of request preams
3 Burst mode
4 Burst option
4 Device Information 1 Field device info 1 Tag
2 Date
3 Descriptor
4 Message
5 Model
6 Write protect
7 Revision #’s
8 Final assembly #
9 Device ID
10 Distributor
2 Sensor information
3 Meter type
4 Self test
5 Review
2 PV
3 AO
4 LRV
5 URV
FIGURE 2-6 Generic Online Menu Map
To Next Page
