2.5 MAIN MENU
The Main menu is shown at right. To access the Main menu:
Communicator not connected to a HART device – Press
the Communicator’s ON/OFF key, the first menu to appear
after powering up is a “Poll?” query. Since a device is not
connected, press NO (F4). The Main menu (at right) will
then appear.
Communicator connected to a powered HART device –
Press the Communicator’s ON/OFF key, the Online menu
appears. To access the Main menu, press the LEFT
ARROW/PREVIOUS MENU key until the Main menu
appears. Alternatively, press HOME (F3) to display the
Online menu, followed by the LEFT ARROW/PREVIOUS
MENU key to display the Main menu.
In the Main menu, access an additional menu by either:
• Moving the cursor to the selection using the UP or DOWN arrow key, followed by pressing the
RIGHT ARROW/SELECT key
• Pressing the appropriate number (1-4) on the alphanumeric keypad.
HART Communicator
1->Offline
2 Online
3 Frequency Device
4 Utility
To Next Page
