Siemens 7MF4233 series

UMSITRPDS3-1 Appendix A - Online Configuration Map
November 2005 11-3
4 Detailed setup 1 Sensors 1 Pressure sensor 1 Pressure +
See Note 4 2 (Engineering) Units
2 Temperature sensor 1 Sensor temperature +
3 Device setup, 2 El temperature +
continued in 2 Signal condition 1 Process variables 1 Pressure +
Figure A-1, 2 % range +
Part 1 3 AO +
4 Sensor Temperature +
2 Position correction
3 Zero/span set 1 Keypad input 1 LRV
2 URV
3 Pressure (Eng.) Units
4 LSL
5 USL
2 Apply values
4 Damping
5 Transfer function
6 Measuring speed
3 Output condition 1 Analog output 1 AO +
2 Pressure
3 Alarms >
4 Lower AO limit
5 Upper AO limit
2 HART output 1 Poll address
2 Num request preambles
3 Num response preambles
4 Device information 1 Ranges and limits 1 Module range
2 Pressure USL
3 Pressure LSL
4 Pressure minimum span
2 Common device 1 Manufacturer
information 2 Model
3 Measurement type
4 Device order number
5 Explosion protection
6 Device ID
7 Pressure sensor S/N
8 Final assembly number
9 Electrical connector
Electrical housing material
Write protect
Tag
Date
Descriptor
Message
3 Sensor information 1 Process connection
2 Flange type
3 Flange material
4 Process flange bolt
5 Isolator material
6 Fill fluid
7 O-ring material
8 Drain & vent/plug material
9 Drain & vent/plug position
4 Remote seal 1 RS type
2 RS isolator material
3 RS fill fluid
4 Number of remote seal
5 Extension length
5 Local meter 1 Meter type
2 Unit tracking
3 Local display units
4 Bargraph
6 Revision numbers 1 Universal rev.
2 Field device revision
3 Software revision
4 Hardware revision
5 Reviews Step through configuration
FIGURE 11-2 Online Configuration Map, Part 2 of 2
