Siemens 7MF4233 series

UMSITRAPDS3-1 Model Designations and Specifications
November 2005
9-7
Other versions
Add "-Z" to order number and add short specification
7MF4333 - . . . . . - . . . . - Z
Transmitter with mounting bracket of:
- steel
A01
- stainless steel
A02
Process flange O-ring (instead of FPM (Viton)) of:
- PTFE (Teflon)
A20
- FEP (with silicone core, foodstuff compatible)
A21
- FFPM (Kalrez)
A22
- NBR (buna N)
A23
Han 7D plug (metal, gray)
6)
A30
Han 8U plug (instead of Han 7D)
6)
A31
Sealing screw (1/4-18 NPT) with valve in same material as process flange
A40
Labeling of rating plate (instead of German):
- English
B11
- French
B12
- Spanish
B13
- Italian
B14
Manufacturer test certificate M acc. to DIN 55 350, Part 18, and per ISO 8402
C11
Acceptance test certificate B acc. to DIN 50 049 / EN 10 204-3.1 B
C12
Works certificate acc. to DIN 50 049-2.2 / EN 10 204-2.2
C14
Setting of the upper output signal limit to 22.0 mA
D05
Acid gas version according to NACE: Only with Hastelloy process diaphragm and
stainless steel process flange screws
D07
IP 68 (not with Han 7D/Han 8U plug or cable screwed gland Pg 13.5)
D12
Application in zone 0 (basic device EEx ia)
4) 6)
E02
Side vent for gas measurement
4)
H02
Process flange:
- without process flange
K00
- Hastelloy flange
7)
K01
- Monel flange
7)
K02
Measuring range to be set, specify in clear text:
Y01: 0 to ... mbar, psi, kPa, MPa, ... (27 characters maximum)
Y01
Tag number / description (16 characters maximum), specify in clear text:
Y15
Tag message (27 characters maximum) specify in clear text:
Y16
Setting digital display, specify in clear text
Analog display, specify in clear text: mbar, psi, kPa, MPa, ...
Y20
Factory pre-settings other than "Y01", "Y20" and "D05" are not possible.
Notes:
1)
Only with stainless steel process flange screws
5)
Not with explosion proof degree of protection
2)
Version 7MF4333-1DY - Only up to a maximum span of 2.9 psi
6)
Not FM approved
3)
Not for span G, H, or K
7)
Maximum PN 2320 psi static
4)
Without cable screwed gland
